Filter Cartridge

Ceramic Fiber Hot Gas Filter Cartridge

Name: Ceramic Fiber Hot Gas Filter Cartridge
Brand: Shine Technology
Availability: PreOrder

Porous ceramic-fiber element for high-temperature flue-gas dust removal and optional integrated catalytic treatment.

Filter Cartridge Series

Ceramic Fiber Hot Gas Filter Cartridge

Hot gas filter, also named ceramic fiber filter, is a porous sintered filter element specially developed for high-temperature flue gas working conditions. It adopts vacuum forming and high-temperature curing to form a gradient porous fiber structure that removes fine particles such as PM2.5 and PM10. Non-catalytic elements remove solid dust, fume and soot; catalyst-coated elements combine dedusting, denitrification and dioxin decomposition in one unit.

Main raw materialHigh-purity alumino-silicate fiber

Al₂O₃ content45–48%

SiO₂ content51–54%

Total oxide purity≥99.6%

Impurities (Na, K, Mg, Ca)≤0.3%

Single fiber diameter2.5–3.5 μm

Get a Free Quote Request Sample Technical Data

Product Description

Key Features

Extreme high-temperature resistance

Excellent chemical and corrosion resistance

Ultra-high filtration precision

Long service life with low maintenance

Multi-pollutant treatment with the catalytic version

Low system operating cost

Technical Specifications

Parameter	Ceramic Fiber Hot Gas Filter Cartridge	Custom Range
Main raw material	High-purity alumino-silicate fiber	Customizable on request
Al₂O₃ content	45–48%	Customizable on request
SiO₂ content	51–54%	Customizable on request
Total oxide purity	≥99.6%	Customizable on request
Impurities (Na, K, Mg, Ca)	≤0.3%	Customizable on request
Single fiber diameter	2.5–3.5 μm	Customizable on request
